Multimeter UT890D+ Uni-T

Measurement Range

• DC voltage: 600 mV / 6 V / 60 V / 600 V / 1000 V ±(0.5%+2)


• AC voltage: 6 V / 60 V / 600 V / 750 V ±(0.8%+3)


• DC current: 60 uA / 600 uA / 6 mA / 60 mA / 600 mA / 20 A ±(0.8%+8)


• AC current: 60 uA / 600 uA / 6 mA / 60 mA / 600 mA / 20 A ±(1%+12)


• Resistance: 600 Ohm / 6 kOhm / 60 kOhm / 600 kOhm / 6 MOhm / 60 MOhm ± (0.8% + 3)


• Capacitance: 6 nF /60 nF / 600 nF / 6 µF / 60 µF / 600 µF / 6 mF / 60 mF / 100 mF ±(3%+10)
  ACV Frequency: 10Hz~10kHz ±(0.1%+5)


• Frequency: 9.999 Hz ~ 9.999 MHz (1%+5)


• HFE measurement of transistors


• Diode test


• Circuit continuity check

• NCV (electric field detection function)


• Manually changing measurement ranges


• Detection of power lines


• True RMS


• Blown fuse notification


• Overload warning: >= 20 A


• REL function: reset reading


• Freezing the last reading


• Screen backlight


• Maximum/minimum value recording


• Sound/light signal: during continuity and NCV measurement


• Automatic shutdown


• Low battery indicator


• Maximum reading: 6000

• Power supply: 2x AAA 1.5 V batteries


• Screen size: 56.5 x 36 mm


• Product dimensions: 183x88x56 mm


• Product weight: 346 g


• Operating temperature: 0°C ~ 40°C (32°F ~ 104°F)


• Storage temperature: -10°C ~ 50°C (14°F ~ 122°F)


• Relative humidity: 0°C ~ 30°C =<75%, 30°C ~ 40°C =<50%


• Operating altitude: 0 ~ 2000 m
